LiMing/Gas series



Shangchai Dongfeng branded engines, Feijing branded engines and applied The gas could be natural gas, Marsh gas,liquid gas, etc Shanghai Dongwo,Jiangsu Uming TFW series brushless motors, featured by H insulation class, steel body salient pole integrative rotor punching,are applied,to ensure high and stable performance MARATHON,SITANFU and SIEMENS branded motors are optional ZZHGM61 l0 Control Panel and mu% functional digital control modules are optional,with Chinese and Englishi interface Manual and automatic control is available And it is easy to combine engines automatically.


Model

Rated power
(KW/KVA)

rated voltage
(V)

Rated frequency
(HZ)

Rated speed
(r/min)

start the way

Manipulating the way

Power factor
(cosφ)

Q135seriesGas generator set

20-80

400/230

50

1500

24VDirect current
24VDC

Automatic  electronic

0.8
(lag)

190Gas generator set

200-300

400/230

50

1500

24VDirect current
24VDC

Automatic electronic

0.8
(lag)

190VGas generator set

400-1000

400/230

50

1000/1500

24VDirect current

Automatic electronic

0.8
(lag)



Gensets
Model

output power
(kw/kva)

voltage
(V)

current
(A)

frequency
(HZ)

speed
(r/min)

power


power
Model

Engine Model

Appearance size
(L*B*H)mm

Unit weight
(kg)

24KW

24/30

400

43.3

50

850

0.8

1190NT

BC184

2885*1290*1420

2000

45KW

45/56

400

81

50

750

0.8

2190T-1

UC224

3310*1500*1795

3700

60KW

45/56

400

108

50

1000

0.8

2190T

UC224

3310*1500*1795

3700

90KW

90/112.5

400

154

50

750

0.8

4190T-1

UC274

3940*1600*1925

5100

120KW

120/150

400

216

50

1000

0.8

4190T

UC274

3940*1600*1925

5100

180KW

180/225

400

324

50

1000

0.8

6190T

HC4

5925*1725*2707

8700

400KW

400/500

400

720

50

1000

0.8

12V190T

HC5

4566*1970*2310
(开式)

11500

400KW

400/500

400

720

50

1000

0.8

12V190T

HC5

5925*1970*2633
(闭式)

13500
